Fuel Dispenser BT-A1
Product Overview:
Features:
*Trustable highly precise metrology equipment
*High performance for electronic parts
*High quality explosion-proof motor with strong ability against power fluctuation
*Specially designed filtering systems with build-in re-cleanable filter
*Flexible fuel application for gasoline, diesel, and kerosene etc.
*Works well in harsh conditions, like extremely cold, hot, humid, and sand-stormy environment
Optional configuration:
Printer，IC card， ID card， communication for FMS, break away, emergency stop, color screen, ect.
Technical specifications:
| Accuracy for the unit | ±0.25% |
| Flow rate | 45L/min |
| Ambient temperature | -25ºC~ +55ºC; -40ºC ~ +50ºC |
| Relative humidity | 20% - 95% |
| Unit noise rate | < 70dB (A); |
| Inlet vacuum rate for suction pump | >= 54kPa |
| Communication | With RS 485 port, or current loop |
| Power supply | AC 220V( -15%~+10%), (50/60±1)Hz ; AC 380V( -15%~+10%); (50/60±1)Hz |
| Digit of sale | 7digits(decimal points can be adjusted ) |
| Digit of volume | 6digits (decimal points can be adjusted ) |
| Digit of unit price | 5digits (decimal points can be adjusted ) |
| Totalizer of sale | 0~42949672.95 |
| Totalizer of volume | 0~42949672.95 |
